S7712(v200r010)未设置端口为边缘端口,日志提示该接口为边缘端口

问题描述

现网运行一S7712交换机,没有将接口配置为边缘端口,但是日志提示该接口为边缘端口。

Nov 28 2018 14:54:30 NB-DSY-02GUI-3U-7712 %%01MSTP/4/EDGE_PORT(l)[27]:Edged-port GigabitEthernet12/1/3 received BPDU packet, then the active state of the edged-port will be disabled!

Nov 28 2018 14:54:28 NB-DSY-02GUI-3U-7712 %%01MSTP/4/EDGE_PORT(l)[28]:Edged-port GigabitEthernet12/1/1 received BPDU packet, then the active state of the edged-port will be disabled!

Nov 28 2018 14:54:28 NB-DSY-02GUI-3U-7712 %%01MSTP/4/EDGE_PORT(l)[29]:Edged-port GigabitEthernet12/1/0 received BPDU packet, then the active state of the edged-port will be disabled!

Nov 28 2018 14:54:28 NB-DSY-02GUI-3U-7712 %%01MSTP/4/EDGE_PORT(l)[30]:Edged-port GigabitEthernet12/1/2 received BPDU packet, then the active state of the edged-port will be disabled!

interface GigabitEthernet12/1/0

description TO WIFI RUIJIE SWITCH

port link-type trunk

port trunk allow-pass vlan 2 to 4094

#

interface GigabitEthernet12/1/1

description TO WIFI RUIJIE SWITCH

port link-type trunk

port trunk allow-pass vlan 2 to 4094

#

interface GigabitEthernet12/1/2

description TO WIFI RUIJIE SWITCH

port link-type trunk

port trunk allow-pass vlan 2 to 4094

#

interface GigabitEthernet12/1/3

description TO RUIJIE WIFI 4

port link-type trunk

port trunk allow-pass vlan 2 to 4094

解决方案

经核实:端口使能生成树协议后,会默认启用边缘端口自动探测功能,当端口在(2 × Hello Timer + 1)秒的时间内收不到BPDU报文,自动将端口设置为边缘端口,否则设置为非边缘端口。

----[Port29(GigabitEthernet12/1/12)][FORWARDING]----

Port Protocol       :Enabled

Port Role           :Designated Port

Port Priority       :128

Port Cost(Dot1T )   :Config=auto / Active=20000

Designated Bridge/Port   :0.340a-98ae-1df0 / 128.29

Port Edged          :Config=default / Active=enabled
